Sat, Oct 24

saadinnocent909 added a comment to T9502: accel-ppp: VPP crashes (SIGBUS in policer_input_node_fn) when sessions with a rate limit end.

Reviewed PR #46: it is the same reorder I tested in v6 (policer-input removed from the four ip4/ip6 arcs before unbind/delete). Over ~2000 sessions with ~1 Gbit/s policed traffic, 13 resets, 6 CoA rate changes under traffic, Disconnect and reset-all, VPP did not crash (NRestarts 0). Note: the second restart on 10-22 at 14:41:14 UTC was also SIGSEGV in policer_input_node_fn_hsw (not NAT), so both 10-22 crashes match T9502. Happy to run more churn rounds on the merged build.

Sat, Oct 24, 2:34 PM · VyOS Rolling
saadinnocent909 added a comment to T9211: VPP PPPoE with RADIUS Idle-Timeout: sessions drop every 60 s, accounting reports 0 bytes used.

Sure, feel free to quote my v6 results in the T9502 PR. Thanks for picking
up the idle-timeout cause as a separate fix.

Sat, Oct 24, 2:21 PM · VyOS Rolling

Fri, Oct 23

saadinnocent909 added a comment to T9502: accel-ppp: VPP crashes (SIGBUS in policer_input_node_fn) when sessions with a rate limit end.

I will check this tomorrow. By the way I am that 2000 session tester

Fri, Oct 23, 7:06 PM · VyOS Rolling
saadinnocent909 added a comment to T9211: VPP PPPoE with RADIUS Idle-Timeout: sessions drop every 60 s, accounting reports 0 bytes used.

Thanks @ruben-herold. I tested v6 (sha256 047910eb…4a94a5 OK) for a full day. Setup: rolling 2026.10.16-0024, VPP 25.10.0, PPPoE on VPP eth0, FreeRADIUS on a separate VM, rate-limit via Filter-Id (no vendor), 2 MikroTik CPEs + ~2,000 PPPoE load sessions. Installed 11:33 UTC. I removed my LD_LIBRARY_PATH drop-in and it starts fine, so the RUNPATH fix works. accel-pppd ran the whole test with one PID and NRestarts=0, so the EBADF abort (#44) did not come back.

Fri, Oct 23, 2:35 PM · VyOS Rolling
saadinnocent909 added a comment to T9211: VPP PPPoE with RADIUS Idle-Timeout: sessions drop every 60 s, accounting reports 0 bytes used.

I working on it. I will update you once testing is done

Fri, Oct 23, 11:18 AM · VyOS Rolling

Thu, Oct 22

saadinnocent909 added a comment to T9211: VPP PPPoE with RADIUS Idle-Timeout: sessions drop every 60 s, accounting reports 0 bytes used.

I will do the test and let you know

Thu, Oct 22, 3:50 PM · VyOS Rolling
saadinnocent909 created T9501: VPP: NAT44 does not translate traffic of PPPoE server sessions (pppoe_sessionN is not an inside interface).
Thu, Oct 22, 3:25 PM · VyOS Rolling
saadinnocent909 added a comment to T9211: VPP PPPoE with RADIUS Idle-Timeout: sessions drop every 60 s, accounting reports 0 bytes used.

Thanks @ruben-herold, I tested the package accel-ppp-ng-T9211-v2 (#42 + #44).
▎
▎ Setup: fresh VyOS 2026.10.16-0024-rolling VM, VPP 25.10.0 (PPPoE on eth0, NAT44 removed for this test), FreeRADIUS 3.2.5 + PostgreSQL, MikroTik CHR clients: 2 real CPEs + up to ~1,700 PPPoE clients on macvlans. Idle-Timeout = 120 in radgroupreply for the group of the 2 CPEs only. No interim interval configured.
▎
▎ 1. Install: the binaries have no RUNPATH, accel-pppd exits with libtriton.so: cannot open shared object file (libluasupp.so also not found for libradius.so). The stock binary has RUNPATH /usr/lib64/accel-ppp. With a drop-in Environment=LD_LIBRARY_PATH=/usr/lib64/accel-ppp it starts.
▎
▎ 2. #44 works. reset pppoe-server username usman with the other sessions up: same accel-pppd PID before and after, no EBADF/ABRT in the journal. Also reset pppoe-server all with ~1,500 sessions: the daemon stayed up (NRestarts=0). On stock the first teardown aborts the daemon (backtrace triton_md_disable_handler <- destablish_ppp, same as your strace).
▎
▎ 3. Idle-Timeout (#42) — not fixed yet in my test. radacct for the CPE user usman:
▎ - stock: 7 of 9 sessions ended after exactly 60 s with Acct-Terminate-Cause = NAS-Error, all with 0 bytes.
▎ - with the package: rx bytes are counted now (e.g. 477 B), but sessions still end with NAS-Error: 4 sessions after 60 s or 120 s while VPP was up (two more ended around the VPP restart in point 5). None ended with Idle-Timeout.
▎
▎ 4. Counters drop to 0 under load. When ~1,000 sessions connected within a minute (19:37-19:38 local), the counters of the two CPE sessions went from 1.4 KiB / 477 B to 0 B, and usman ended with NAS-Error at the next timer tick (19:38:48). I think this is the heartbeat check: /sys/heartbeat in the stats segment changes about every 10 s, so the 3 s / 10 s "VPP instance lost" limits trigger while VPP is busy, the stats read returns an error and the session is ended. In my own build of dd07b23 + #42 + #44 I raised those limits to 35 s; with that, two CPE sessions stayed up 19 h with ~2,000 sessions online and the counters stayed correct.
▎
▎ 5. VPP worker crashes (not caused by #44, but #44 makes this path run).
▎ - 13:44:52 UTC, ~1,500 sessions, sessions being torn down: received signal SIGBUS in policer_input_node_fn_hsw, vpp-failure-handler restarted VPP, all sessions dropped.
▎ - 14:41:22 UTC VPP restarted again with ~1,700 sessions and no config change: [VPP 14:41].
▎
▎ My guess for the policer crash: vpppolicer_remove_limiter() first calls policer_input(apply=0) — VPP sets policer_index_by_sw_if_index to ~0 and only disables the device-input arc — then deletes the policer, and only after that disables the policer-input features on the ip4/ip6 unicast/multicast arcs (added by vyos-vpp-patches 0018). A packet in that window reads pm->policers[~0]. Disabling those four features before vpppolicer_set_input(0, ...) should close it. CoA reaches the same code through install_limiter(). Before #44 this path was never reached, because the daemon aborted first.

Thu, Oct 22, 3:02 PM · VyOS Rolling
saadinnocent909 added a comment to T9211: VPP PPPoE with RADIUS Idle-Timeout: sessions drop every 60 s, accounting reports 0 bytes used.

Ok I will test these today. And will share all my findings with you

Thu, Oct 22, 9:58 AM · VyOS Rolling
saadinnocent909 added a comment to T9211: VPP PPPoE with RADIUS Idle-Timeout: sessions drop every 60 s, accounting reports 0 bytes used.

I do understand that. I will update you today, after thorough testing Insha
Allah

Thu, Oct 22, 8:05 AM · VyOS Rolling

Wed, Oct 21

saadinnocent909 added a comment to T9211: VPP PPPoE with RADIUS Idle-Timeout: sessions drop every 60 s, accounting reports 0 bytes used.

I did some testing with patch. Counters started working and I started to
get usage in freeradius interim accounting updates. But I also noticed
another issue if I kick a user using reset command all users are
disconnected. Tomorrow I will share stats as well and will do some more
testing. Idle timeout and session timout I will check these as well
tomorrow

Wed, Oct 21, 8:15 PM · VyOS Rolling

Tue, Oct 20

saadinnocent909 added a comment to T9211: VPP PPPoE with RADIUS Idle-Timeout: sessions drop every 60 s, accounting reports 0 bytes used.

Tomorrow I will give it a try and update you.

Tue, Oct 20, 6:01 PM · VyOS Rolling
saadinnocent909 added a comment to T9211: VPP PPPoE with RADIUS Idle-Timeout: sessions drop every 60 s, accounting reports 0 bytes used.

can you share me patched iso or lates rolling release includes the PR ?

Tue, Oct 20, 2:10 PM · VyOS Rolling
saadinnocent909 added a comment to T9211: VPP PPPoE with RADIUS Idle-Timeout: sessions drop every 60 s, accounting reports 0 bytes used.

I can test

Tue, Oct 20, 6:36 AM · VyOS Rolling

Mon, Oct 19

saadinnocent909 added a comment to T9211: VPP PPPoE with RADIUS Idle-Timeout: sessions drop every 60 s, accounting reports 0 bytes used.

I was testing vyos as BNG for my network especially with vpp. But I faced same issue. I hope issue will be resolved soon

Mon, Oct 19, 9:33 PM · VyOS Rolling
